Xournal on Windows
Screenshot of Xournal running natively on Windows Vista
Xournal is a free software note-taking application similar to Microsoft Windows Journal. It used to be Linux-only, with MacOS and Windows ports on the TODO list. But as you can see it is now possible to run it on Windows. Hopefully a nice installer can be created for it, like the ones for Inkscape and Gimp, but for now the process is rather tricky and involves editing and compiling Xournal’s source code.
Update: Denis Auroux, the author of Xournal, has graciously incorporated my code changes into Xournal and made an official Windows release available on the Xournal homepage. Go try it out!
Here’s what I did:
Step 1: Setting up the development environment
We’ll need to set-up a compiler and install all the libraries that Xournal uses (directly or indirectly) before we can compile its source code. Here are the software packages I installed with their version numbers (newer versions will probably work, significantly older versions might not), website addresses (I’d provide direct download links, but they’ll probably end up as dead links as soon as version numbers change), and where I installed them (of course, you’ll probably want to use different paths, unless your name is also Dirk):
MinGW + MSys, a minimalist Unix-like environment for Windows, for the C compiler and other build tools. These can be gotten from MinGW.org:
-
MinGW 5.1.4 (into c:/Users/Dirk/Programming/MinGW)
-
MSys 1.0.11 (into c:/Users/Dirk/Programming/msys)
-
perl 5.6.1_2-1 (into c:/Users/Dirk/Programming/msys/1.0)
-
libcrypt 1.1_1-2 (into c:/Users/Dirk/Programming/msys/1.0)
-
autoconf 2.63-1 (into c:/Users/Dirk/Programming/msys/1.0)
-
automake 1.11-1 (into c:/Users/Dirk/Programming/msys/1.0)
Some Gtk+ and GNOME libraries that Xournal uses for its GUI. These can be gotten from Gtk.org:
-
Gtk+ 2.16.5-20090731 development bundle (into c:/…/MinGW)
-
Cairo 1.8.8-2 binary+dev package (into c:/…/MinGW, overwriting the one from the bundle because the latter is apparently built without FreeType support)
-
FreeType 2.3.9-1 binary+dev package (into c:/…/MinGW)
-
fontconfig 2.7.1-2 binary+dev package (into c:/…/MinGW)
-
win_iconv 20080320 binary+dev package (into c:/…/MinGW)
-
libgnomecanvas 2.20.1 binary+dev package (into c:/…/MinGW)
-
libgnomeprintui 2.12.1 binary+dev package (into c:/…/MinGW)
-
libgnomeprint 2.12.1 binary+dev package (into c:/…/MinGW)
-
libart_lgpl 2.3.20 binary+dev package (into c:/…/MinGW)
and more GNOME.org:
-
libxml 2.7.3 binary+dev package (into c:/…/MinGW)
-
expat 2.0.1-1 binary package (into c:/…/MinGW)
In the C:/Users/Dirk/Programming/MinGW/lib/pkgconfig/libgnomeprint-2.2.pc file we have to make a small change, replacing “pango” by “pangoft2″ on the “Requires:” line, so that in now reads:
Requires: libart-2.0 glib-2.0 gmodule-2.0 gobject-2.0 libxml-2.0 pangoft2
Step 2: Building libpoppler from source
The above gave us all the libraries Xournal needs, except for Poppler. I haven’t seen a pre-compiled binary version for Windows, so we’ll have to build it ourselves. We simply download the Poppler source code, start MSys, cd into the directory where we unpacked the source code, and type:
$ export ACLOCAL_FLAGS=-I/c/Users/Dirk/Programming/MinGW/share/aclocal/ $ ./configure --prefix=/c/Users/Dirk/Programming/MinGW/ $ make $ make install
(Don’t type the dollar signs, they just indicate the MSys prompt.)
Step 3: Removing Xournal’s screenshot functionality
Once we’ve downloaded Xournal’s source code from the Xournal website, we can’t immediately compile it for Windows. Xournal has one bit of functionality that’s not implemented with the cross-platform Gtk+ library, but instead is implemented directly using X. This will of course not work on different platforms such as Windows.
The functionality in question is in the menu under “Journal > Background screenshot”. On Linux, it hides the Xournal window, then when you click anywhere it’ll bring back the Xournal window with an added screenshot of whatever window you clicked on. There is no way to implement this “clicking on a window”-mechanic in the Windows API, so a proper fix would be to change the mechanic to something different, as the Gimp guys have done. There one drags a crosshair onto a window.
I have not taken the effort to actually implement this different screenshot mechanic, as I don’t use it and it’s a lot easier to just remove it:
-
In src/xo-misc.c in the function hide_unimplemented at the bottom of the file add the lines
#ifdef WIN32 gtk_widget_hide(GET_COMPONENT("journalScreenshot")); #endif -
In src/xo-file.c at the top of the file, disable the X-specific #includes under Windows:
#ifndef WIN32 # include <gdk/gdkx.h> # include <x11/Xlib.h> #endif
-
In the same file, replace the body of the attempt_screenshot_bg function to do nothing on Windows:
struct Background *attempt_screenshot_bg(void) { #ifndef WIN32 ... old body here ... #else /* WIN32 */ return NULL; #endif }
Step 4: Building Xournal from source
To build Xournal, we just use MSys as before, and inside the xournal directory type the following:
$ export ACLOCAL_FLAGS=-I/c/Users/Dirk/Programming/MinGW/share/aclocal/ $ ./autogen.sh $ make
Step 5: Running Xournal
To run Xournal we can type
$ src/xournal
or just double-click src/xournal.exe in Windows’s explorer.
If all went well, you’ll see that Xournal “works”, but has some bugs. I’ll describe below how to fix each of these by editing Xournal’s source code. Recompiling (that is, repeating Step 4) will then give you a truly working Xournal. If you don’t want to manually apply all my fixes, you can just download the resulting source code.
Cursor is a black square and loading/saving doesn't work.
Bug 1: The cursor is a big black square
For the pen and highlighter tools, you’ll notice that the cursor is always a 16×16 black square, regardless of the selected color. This is a defect in GDK’s Windows backend (Bug 541377). The function gdk_cursor_new_from_pixmap, which Xournal uses, will only give you monochrome cursors on Windows, and produces strange results when trying to produce a colored cursor.
While this should be fixed on the GDK end, a workaround is to just use different functions from GDK to create colored cursors. This can be done by putting the following code near the top in src/xo-paint.c:
#ifdef WIN32
gboolean colors_too_similar(const GdkColor *colora, const GdkColor *colorb)
{
return (abs(colora->red - colorb->red) < 256 &&
abs(colora->green - colorb->green) < 256 &&
abs(colora->blue - colorb->blue) < 256);
}
/* gdk_cursor_new_from_pixmap is broken on Windows.
this is a workaround using gdk_cursor_new_from_pixbuf. */
GdkCursor* fixed_gdk_cursor_new_from_pixmap(GdkPixmap *source, GdkPixmap *mask,
const GdkColor *fg, const GdkColor *bg,
gint x, gint y)
{
GdkPixmap *rgb_pixmap;
GdkGC *gc;
GdkPixbuf *rgb_pixbuf, *rgba_pixbuf;
GdkCursor *cursor;
int width, height;
/* HACK! It seems impossible to work with RGBA pixmaps directly in
GDK-Win32. Instead we pick some third color, different from fg
and bg, and use that as the 'transparent color'. We do this using
colors_too_similar (see above) because two colors could be
unequal in GdkColor's 16-bit/sample, but equal in GdkPixbuf's
8-bit/sample. */
GdkColor candidates[3] = {{0,65535,0,0}, {0,0,65535,0}, {0,0,0,65535}};
GdkColor *trans = &candidates[0];
if (colors_too_similar(trans, fg) || colors_too_similar(trans, bg)) {
trans = &candidates[1];
if (colors_too_similar(trans, fg) || colors_too_similar(trans, bg)) {
trans = &candidates[2];
}
} /* trans is now guaranteed to be unique from fg and bg */
/* create an empty pixmap to hold the cursor image */
gdk_drawable_get_size(source, &width, &height);
rgb_pixmap = gdk_pixmap_new(NULL, width, height, 24);
/* blit the bitmaps defining the cursor onto a transparent background */
gc = gdk_gc_new(rgb_pixmap);
gdk_gc_set_fill(gc, GDK_SOLID);
gdk_gc_set_rgb_fg_color(gc, trans);
gdk_draw_rectangle(rgb_pixmap, gc, TRUE, 0, 0, width, height);
gdk_gc_set_fill(gc, GDK_OPAQUE_STIPPLED);
gdk_gc_set_stipple(gc, source);
gdk_gc_set_clip_mask(gc, mask);
gdk_gc_set_rgb_fg_color(gc, fg);
gdk_gc_set_rgb_bg_color(gc, bg);
gdk_draw_rectangle(rgb_pixmap, gc, TRUE, 0, 0, width, height);
gdk_gc_unref(gc);
/* create a cursor out of the created pixmap */
rgb_pixbuf = gdk_pixbuf_get_from_drawable(
NULL, rgb_pixmap, gdk_colormap_get_system(), 0, 0, 0, 0, width, height);
gdk_pixmap_unref(rgb_pixmap);
rgba_pixbuf = gdk_pixbuf_add_alpha(
rgb_pixbuf, TRUE, trans->red, trans->green, trans->blue);
gdk_pixbuf_unref(rgb_pixbuf);
cursor = gdk_cursor_new_from_pixbuf(gdk_display_get_default(), rgba_pixbuf, x, y);
gdk_pixbuf_unref(rgba_pixbuf);
return cursor;
}
#define gdk_cursor_new_from_pixmap fixed_gdk_cursor_new_from_pixmap
#endif
Bug 2: Loading and saving doesn’t work
Using our Windows version of Xournal to try to load a file saved by Xournal on Linux gives an error message. What’s more, a file saved with our Windows version of Xournal gives an error message when trying to load it with Xournal on either platform!
It took me quite a while to figure this out, but the culprit here is that Xournal uses zlib in the wrong way, namely with text-mode I/O instead of binary I/O. This bug doesn’t show up on Linux because there text-mode and binary I/O are pretty much the same thing. On Windows, however, text-mode I/O converts a '\n' character into "\r\n" on writing, and vice versa on reading. This is fine for text documents, but not for binary files such as Xournal’s!
The fix is simple: replace text I/O modes ("r" and "w") by binary I/O modes ("rb" and "wb") in all the relevant gzopen, popen, and fopen calls. That is, all the calls in src/xo-print.c and all the calls in src/xo-file.c except for
f = fopen(ui.mrufile, "w");
in save_mru_list, and
f = fopen(ui.configfile, "w");
in save_config_to_file.
Bug 3: Fullscreen isn’t truly fullscreen
When I tried Xournal’s fullscreen mode, I could still see the Windows taskbar. This seems to be a bug in the gtk_window_fullscreen function on Windows. Inkscape’s fullscreen functionality does work properly, however, and that also uses gtk_window_fullscreen. It’ll take some more detective work to pin this down properly, but in the meantime it is fairly easy to work around.
-
In src/xournal.h, add two new fields to the UIData struct:
gint pre_fullscreen_width, pre_fullscreen_height;
-
In src/xo-callbacks.c, in the on_viewFullscreen_activate function, replace the two lines
if (ui.fullscreen) gtk_window_fullscreen(GTK_WINDOW(winMain)); else gtk_window_unfullscreen(GTK_WINDOW(winMain));
by the lines
if (ui.fullscreen) { gtk_window_get_size(GTK_WINDOW(winMain), &ui.pre_fullscreen_width, &ui.pre_fullscreen_height); gtk_window_fullscreen(GTK_WINDOW(winMain)); gtk_widget_set_size_request(GTK_WIDGET(winMain), gdk_screen_width(), gdk_screen_height()); } else { gtk_widget_set_size_request(GTK_WIDGET(winMain), -1, -1); gtk_window_unfullscreen(GTK_WINDOW(winMain)); gtk_window_resize(GTK_WINDOW(winMain), ui.pre_fullscreen_width, ui.pre_fullscreen_height); }
With all of the above fixes, compiling the resulting source code gives a working version of Xournal on Windows (minus the screenshot functionality).
